MILLS FORMWORK

M P 3 M I L L S S E C O N D A R Y B E A M S F O R Q U I C K F O R M W O R K 4 NT 009 - MILLS FORMWORK TECHNICAL INFORMATION MILLS MP3 Secondary beams made from aluminium..... > MP3 beams, for safe installation of plywood: T he MP3 formwork system is a set of 3 beams connected together by a handle that secures the installation of the plywood during the formwork of the concrete slabs. The small spacing between the beams (10 cm) prevents a foot from passing through and protects from the risks of falling. Also, the overlaping zones of the MP3 make moving about easier. MP1 unit beams are used for the keys. The complex shapes are carried out using standard lumber that have the same height as the MP3 and MP1. The MP3 beams are delivered in specific cradles that do not require metal straps and their light weight of 14.8 kg makes installation easy. 100 1.90 m 75 425 Height of the beam corresponds to that of a standard wood lumber (75x63). Protective cap Wooden battens MP3: Mills Beams x 3... Advantages: > Secures the installation of the plywood. > Space between beams: 10 cm. > Tipping is impossible. > Quick assembly. > 2 wooden battens. >Weight MP3: 14.8 kg. > About 0.80m² formworked by MP3. > Supplemented simply in tight areas with MP1 unit beams and lumber. > Special storage cradle. E S P A C E E N T 1 0 C Details of the clip to flange the MP3 to the Phal P1 beams.
